Outdoor Portable Machine Vision Lens P Iris 1/1.8" Manual Zoom 12-50mm

Basic Information
Place of Origin: China
Brand Name: Octavia
Certification: CE, FCC, RoHS
Model Number: MR-F1250AS-3MP
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: The inside is packed by blister box usually, the outer is packed by carton
Delivery Time: The regular products will be ready within 3 to 7 days, special models will need about 30 days
Payment Terms: T/T, L/C, PAYPAL, WEST UNION
Supply Ability: 1000000pcs/month
Model:: MR-F1250AS-3MP Mount:: CS
Focal Length:: 12-50mm Image Format:: 1/1.8″
Aperture:: F1.5 Field Angle(1/3%22):: 33°-8°6'
Iris: Auto Focus: Manual With Lock
Zoom: Manual With Lock
High Light:

cctv board lens

,

ip camera wide angle lens

3MP HD Megapixels 12-50mm Manual Zoom P-Iris 1/1.8" CS Mount CCTV Lens For HD IP Security Camera



Features:
1. 3.0 megapixel HD lens,12-50mm F1.5 Manual Iris Vari-focal length Lens Machine Vision Lens
2. 1/1.8" Format High quality auto iris cctv lens,optical lens ,CS Mount Lens
3. 12-50mm focal length Manual Iris Lens,security lens
4. Low distortion Lens for box camera,Surveillance Lens, Industrial Camera Lens
5. This high resolution cctv lens can capture the all resolution of mega pixel camera,IP camera & High resolution camera.





Specification

Model MR-F1250AS-3MP Mount CS mount
Focal Length 12-50mm Iris Auto
Sensor Size 1/1.8" Weight 155g
Aperture F1.5 Dimension Φ40x84.85mm
MOD 0.2m Resolution 3.0MP
HFOV 33°-8°6' BFL 7.45mm
Application Industrial machine vision lens









Advantages and characteristics of lens:
1. Day & Night
With special design, IR series lenses make the portrait aberration lowest, and the focal planes for the visible and infrared light ranges almost the same, which means that the surveillance camera can deliver sharp images in both day and night applications.
2. Flat Image
With the use of advanced optical design technology, our lenses can get high definition and high contrast performance over the entire image field, from the center to the periphery. Also, these lenses are the most suitable for the image cut-out function of IP cameras.
3. Multi Coating
To minimize double image and flare present in backlight, multi coating is adhered to the lens surface. Hence, the lenses can show high contrast resolution performance even in backlight.
4. High resolution lens
The pixels of high resolution lenses are beyond 3.0 Megapixel



Our Service:

1. Reply your enquiry in 24 working hours.

2. 12 Months warranty for all Octavia products.

3. Customized design is available. OEM are welcome.

4. Experienced engineers can solve all your technical problems

5. Goods will ship within 3 working days after received the verified payment.

6. We insist on providing excellent quality with prompt delivery and outstanding after-service at the possible price to our valued customers. We are always looking forward to building a good long-term cooperation relationship with customers.

3MP HD Megapixels 12-50mm Manual Zoom P-Iris 1/1.8" CS Mount CCTV Lens For HD IP Security Camera

Tag: Industrial Lens, Machine Vision Lens
